Zirconium oxide powder

Zirconium oxide powder is a kind of composite material, which is used in the research and development and production of ceramics. Zirconia powder can not only improve the fracture toughness of the substance, but also improve its bending strength.

Easy ways to get the answers you need.Send Email

xlabrasivematerial@gmail.com


Get Price
Properties Advantages Application Related Products Inquiry

Zirconium Oxide Powder

Zirconium oxide powder is a kind of composite material, which is used in the research and development and production of ceramics. Zirconia powder can not only improve the fracture toughness of the substance, but also improve its bending strength.

Properties

White powder, odorless and tasteless crystals, refractory to water, hydrochloric acid and dilute sulfuric acid, chemically not active, have the properties of high melting point, high resistivity, high refractive index and low thermal expansion coefficient.

  • Physical Properties:
  • Non-poisonous Tasteless Solid
  • Bending strength (MPA):
  • 1200
  • Fracture toughness:
  • 8-12
  • BET:
  • 6-25g m2 per g
  • Water Solubility:
  • Insoluble
  • Melting Point:
  • 2700 °C

Advantages

  • The product has good sintering performance, easy sintering, stable shrinkage ratio and good sintering shrinkage consistency.
  • The sintered body has excellent mechanical properties, high strength, hardness and toughness.
  • It has good fluidity, suitable for dry pressing, isostatic pressing, 3D printing and other molding processes.

Application

  • 01

    Piezoelectric ceramics and high temperature resistant materials.

  • 02

    Ceramic insulation materials, color glaze, ceramic brakes, and zirconium gems.

  • 03

    Injection, gel, hot pressing, and injection molding.

Specification

Properties Type Product types
Chemical Composition  Normal ZrO2 High purity ZrO2  3Y ZrO2 5Y ZrO2 8Y ZrO2
ZrO2+HfO2 % ≥99.5 ≥99.9 ≥94.0 ≥90.6 ≥86.0
Y2O3 % ----- ------ 5.25±0.25 8.8±0.25 13.5±0.25
Al2O3 % ﹤0.01 ﹤0.005 0.25±0.02 ﹤0.01 ﹤0.01
Fe2O3  % ﹤0.01 ﹤0.003 ﹤0.005 ﹤0.005 ﹤0.01
SiO2 % ﹤0.03 ﹤0.005 ﹤0.02 ﹤0.02 ﹤0.02
TiO2 % ﹤0.01 ﹤0.003 ﹤0.005 ﹤0.005 ﹤0.005
Water Composition(wt%) ﹤0.5 ﹤0.5 ﹤1.0 ﹤1.0 ﹤1.0
L.O.I(wt%) ﹤1.0 ﹤1.0 ﹤3.0 ﹤3.0 ﹤3.0
D50(μm) ﹤5.0 ﹤0.5-5 ﹤3.0 ﹤1.0-5.0 ﹤1.0
Surface area(m2/g) ﹤7 3-80 6-25 8-30 8-30
Properties Type Product types
Chemical Composition  12Y ZrO2 Yello Y stabilized  ZrO2 Black Y stabilized  ZrO2 Nano ZrO2 Thermal spray ZrO2
ZrO2+HfO2 % ≥79.5 ≥94.0 ≥94.0 ≥94.2 ≥90.6
Y2O3 % 20±0.25 5.25±0.25 5.25±0.25 5.25±0.25 8.8±0.25
Al2O3 % ﹤0.01 0.25±0.02 0.25±0.02 ﹤0.01 ﹤0.01
Fe2O3  % ﹤0.005 ﹤0.005 ﹤0.005 ﹤0.005 ﹤0.005
SiO2 % ﹤0.02 ﹤0.02 ﹤0.02 ﹤0.02 ﹤0.02
TiO2 % ﹤0.005 ﹤0.005 ﹤0.005 ﹤0.005 ﹤0.005
Water Composition(wt%) ﹤1.0 ﹤1.0 ﹤1.0 ﹤1.0 ﹤1.0
L.O.I(wt%) ﹤3.0 ﹤3.0 ﹤3.0 ﹤3.0 ﹤3.0
D50(μm) ﹤1.0-5.0 ﹤1.0 ﹤1.0-1.5 ﹤1.0-1.5 ﹤120
Surface area(m2/g) 8-15 6-12 6-15 8-15 0-30
Properties Type Product types
Chemical Composition Cerium  stabilized ZrO2 Magnesium stabilized ZrO2 Calcium stabilized ZrO2 Zircon aluminum composite powder
ZrO2+HfO2 % 87.0±1.0 94.8±1.0 84.5±0.5 ≥14.2±0.5
CaO ----- ------ 10.0±0.5 -----
MgO ----- 5.0±1.0 ------ -----
CeO2 13.0±1.0 ------ ------ ------
Y2O3 % ----- ------ ------ 0.8±0.1
Al2O3 % ﹤0.01 ﹤0.01 ﹤0.01 85.0±1.0
Fe2O3  % ﹤0.002 ﹤0.002 ﹤0.002 ﹤0.005
SiO2 % ﹤0.015 ﹤0.015 ﹤0.015 ﹤0.02
TiO2 % ﹤0.005 ﹤0.005 ﹤0.005 ﹤0.005
Water Composition(wt%) ﹤1.0 ﹤1.0 ﹤1.0 ﹤1.5
L.O.I(wt%) ﹤3.0 ﹤3.0 ﹤3.0 ﹤3.0
D50(μm) ﹤1.0 ﹤1.0 ﹤1.0 ﹤1.5
Surface area(m2/g) 3-30 6-10 6-10
